Tipping  Semitrailers from 2 to 4 Axles


Chassis & Superstructure

  • Chassis Material: High-tensile steel ST52-3 or ST96-2

  • Cross Members: Double-sided welded steel profiles

  • Side Rails: Integrated longitudinal side members

  • Body Construction: Tipping hopper in Hardox, aluminum, or standard steel

  • Landing Gear: Mechanical, dual-speed landing legs (JOST), 24-ton capacity

  • Kingpin: SAE 2" (standard); convertible to SAE 3.5"

  • Tailgate:

    • Mechanical rear door (standard)

    • Automatic tailgate (optional)

  • Hydraulic Cylinder: 5-stage telescopic tipping cylinder (HYVA or equivalent)

  • Hydraulic System Pressure: Nominal operating pressure ~200 bar

  • Tipping Angle: Approx. 45°–50° depending on body design

  • Cover System: Manual or automatic tarpaulin system (optional)

  • Electrical System:

    • ISO 7638 plug

    • 24V wiring

    • Plug socket and holder for hazard lights

Axles, Suspension & Brake System

  • Axle Brands: BPW, SAF, Gigant, TRAX, KOC, PLT (customer choice)

  • Axle Capacities: Standard load range: 9 / 12 / 14 / 16 tons per axle

  • Suspension Types:

    • Air suspension

    • Steel leaf suspension

    • Boogie suspension (multi-axle articulation)

  • Lift Axle: Standard or on request

  • Steering Axle:

    • Self-steering axle (optional)

    • Hydraulic steering axle (optional)

  • Tyres:

    • Size: 385/65 R22.5 or custom size

    • Brands: Goodyear, Pirelli, Michelin, or equivalent

  • Brake System:

    • Dual-circuit pneumatic (2-channel)

    • Load-sensing valve (automated response to payload)

    • Spring-actuated parking brake

  • Slack Adjusters: Automatic, WABCO or Haldex

  • Electronic Safety Systems: ABS or EBS (as per customer/regional standard)

Paint & Surface Treatment

  • Surface Preparation: Shot-blasted to SA 2.5 standard

  • Primer: Zinc-rich epoxy base coat

  • Finish Paint:

    • 2-component polyurethane coating

    • Oven-cured

    • Color: Any RAL tone per client requirement
